New 5W ECO Fire Rated Led Downlight-B
Short Description:
CODE：5RS131-4/5/6
●Supper budget led fire rated downlight.
●High efficiency led chip up to 100lm/w.
●Dimmable with most leading edge and trailing edge dimmers.
●Different color finishes available in white, chrome, brushed steel.
●Tool free connector Loop in&loop out.
SPECIFICATION
| Power | Code | CCT | Size（A*B） | Cut Out | Lumen Efficacy(max) |
| 5W | 5RS131-4 | 3000K | 81*66 | φ70 | ≥100 lm/W |
| 5RS131-5 | 4000K | ||||
| 5RS131-6 | 6000K |
Features & Benefits
- Dimmable with most leading edge and trailing edge dimmers.
- High light output with 500lm benefit from SMD chips, the equivalent of a 50 watt halogen GU10 lamp.
- Different color finishes – White / Brushed Steel / Chrome.
- 40° beam angle for improving distribution of light.
- Fully tested for 30, 60 and 90 minute ceiling types to meet Part B of Building Regulations.
- IP65 rated fascia suitable for bathroom and wet rooms.
- The slim shape can be installed in shallow void ceiling.
- Insulation coverable based on long lifetime.
| Item | Eco Downlight | Cut Out | 55-70mm |
| Part No. | 5RS058 | Driver | Constant Current Driver |
| Power | 6W | Dimmable | Trailing & Leading Edge |
| CCT | 3000K 4000K 6000K | Energy Class | A+++ |
| Output | 500lm 570lm 600lm | Power Factor | > 0.9 |
| Lumens/W | 90 95 100 | Warranty | 3 Years |
| Input | AC 220-240V 50HZ, 0.03A | LED | 7x1W SMD |
| CRI | 80 | Lifespan | 35,000hrs |
| Beam Angle | 38° | Size | Drawings Supplied |
| IP Rating | IP65 fascia | Operating Temp. | -30°C to +40°C |
| BS476-21 | 30mins,60mins,90mins | Certification | CE & ROHS |
